| FUNCTIONAL DISCONNECTION |
Unipolar |
| SAFETY DISCONNECTION |
Unipolar |
| SAFETY CUT-OUT TECHNOLOGY |
Bimetallic disk |
| SAFETY RESET |
Manual |
| MAX ROOM TEMPERATURE |
100 °C |
| RATED CURRENT / VOLTAGE |
16 A / 240 V |
| FUNCTIONAL TEMPERATURE (FACTORY SETTING) |
From 50 °C to 90 °C, according to Customer specification |
| SAFETY CUT-OUT TEMPERATURE (FACTORY SETTING) |
From 50 °C to 115 °C, according to Customer specification |
| FUNCTIONAL TEMPERATURE HYSTERESIS |
8 °C +/- 4 °C |
| STANDARD STEM LENGHT |
11″ (280 mm) |
| STEM LENGHT ON REQUEST |
7″ (180 mm) / 18″ (450 mm) |
| ELECTRICAL CONNECTION TO HEATING ELEMENT |
Screw terminals |
